HBC514 is a nonfluorescent HBC-analog but emits strong green fluorescence upon forming a tight complex with Pepper RNA aptamer. HBC514-Pepper complex enables visualization of RNAs and the fluorescences can be altered flexibly by simple washing and staining in living Pepper-tagged cells[1].
HBC is a GFP fluorophore-like synthetic dye with a structurally rigid electron acceptor and a strong electron donor, nonfluorescent in solution. ‘Pepper’ is able to enhance HBC’s fluorescence more than 3,000-fold and exhibits bright fluorescence when expressed in living cells[1].‘Pepper’ has reduced Mg2+ sensitivity after multiple rounds of optimization, displays a well-defined fluorescent profile with an excitation maximum at 485nm, an emission maximum at 530nm, and excellent brightness[1].HBC514 (2-10 μM) is altered flexibly by simple washing and staining by Pepper based CRISPR imaging in live HeLa cells (expressing sgRNA-Pep1 and dCas9)[1].
| Catalog Number | I045893 |
| CAS Number | 2530161-67-0 |
| Synonyms | 4-[(Z)-1-cyano-2-[4-[2-(dimethylamino)ethyl-methylamino]phenyl]ethenyl]benzonitrile |
| Molecular Formula | C21H22N4 |
| Purity | ≥95% |
| InChI | InChI=1S/C21H22N4/c1-24(2)12-13-25(3)21-10-6-17(7-11-21)14-20(16-23)19-8-4-18(15-22)5-9-19/h4-11,14H,12-13H2,1-3H3/b20-14+ |
| InChIKey | BCLYGBLOTWSFBR-XSFVSMFZSA-N |
| SMILES | CN(C)CCN(C)C1=CC=C(C=C1)C=C(C#N)C2=CC=C(C=C2)C#N |
| Reference | [1]. Chen X, et al. Visualizing RNA dynamics in live cells with bright and stable fluorescent RNAs.Nat Biotechnol. 2019 Nov;37(11):1287-1293. |
